A Glimpse into the Future of Energy: Tokamak Energy’s ST40 Fusion Reactor
Seeing the inside of a nuclear fusion reactor is, for obvious reasons, complicated. We are talking about temperatures of millions of degrees Celsius, hotter than the core of the Sun. However, the British company Tokamak Energy has just provided us with unprecedented images of what is happening inside its ST40 spherical reactor: a video in full color and at the incredible speed of 16,000 frames per second.
An Unprecedented Ballet of Colors. What we see in the video is essentially the choreography of elements within the tokamak. The ST40, like most of these reactors, uses hydrogen isotopes (deuterium in this case) as fuel. When this gas turns into plasma , it emits a characteristic pink light, setting the stage for a breathtaking display. However, the fascinating part begins when researchers introduce lithium , which emits a glowing red hue.
This visual spectacle is not just eye candy; every color and bright filament captured in these images is a gold mine of information. Scientists are leveraging this data to tackle one of the biggest challenges on the long road to commercial fusion energy : how to tame plasma so it doesn’t degrade reactor materials.
What Exactly Are We Seeing? In the intriguing images, small granules of lithium are introduced into the reactor chamber. Upon entering the cooler outer layers of the plasma, the neutral lithium is excited and emits a vivid crimson light. As these granules traverse into the hottest, most dense regions, lithium atoms lose an electron, becoming ionized and glowing greenish.
Once ionized, lithium is no longer free to move without constraint. Instead, it follows the powerful magnetic field lines that confine the plasma. The dancing green filaments we see in the video are literally the lithium tracing the magnetic cage of the reactor.
What Is All This For? The lithium serves as a protective shield for the reactor. Capturing what occurs in color is a challenging task, but it helps scientists determine whether the impurities introduced into the reactor by Tokamak Energy are radiating in the expected locations and if the lithium powders penetrate to the core of the plasma.
This experiment falls under research into a mode of operation known as the “X-point radiator” (XPR). This method uses elements like lithium to allow the plasma edge to radiate heat before it touches the reactor walls. This creates a cooling “atmosphere” that reduces the wear on reactor components while maintaining core performance.
The Advancement of Tokamak Energy. This approach is central to the Dell ST40 upgrade program, which has received funding from both the US and UK energy departments. The aim is to coat all components that face the plasma with lithium, a strategy already validated in other laboratories, such as Princeton, to enhance plasma performance.
Visual diagnostics like these complement the sophisticated systems being incorporated into reactors such as the JT-60SA in Japan. This is currently the most advanced tokamak in the world, employing lasers to indirectly measure plasma temperature and density.
A Global Career. As massive, institutional projects like ITER chart a long-term path—projected to see their first deuterium-tritium experiments by 2039—more agile companies like Tokamak Energy are innovating with new designs and technologies, such as spherical tokamaks and high-temperature superconducting magnets, to speed up the realization of commercial fusion.
The closure of the historic JET reactor in the United Kingdom, which set energy records, marks the end of an era. However, its legacy serves as the foundation for these new advances. This new window into the heart of plasma is not only visually compelling but represents a significant stride toward replicating the energy of stars on Earth. Nuclear fusion has just become a lot more colorful, and this is promising news for our energy future.
